The Yusenn methanol heater is the core thermal management device for new energy commercial vehicles, which solves the problem of low-temperature engine start-up by preheating the methanol engine; As an independent heat source, it provides efficient heating for the driver's cabin or cargo hold, reducing battery energy consumption. In addition, it can also collaborate with battery thermal management to improve battery life and endurance. This device combines economy and environmental friendliness, using methanol as fuel to reduce operating costs and assist commercial vehicles in stable operation in harsh climates.
Integrated design of water pumpYusenn methanol heater water pump integrated for easy installation. |
6000HBrushless motor, quieter and more durable, with a lifespan of up to 6000 hours. |
Energy saving and Environmental ProtectionUsing methanol as fuel, it is energy-efficient and environmentally friendly, meeting the independent heating needs of new energy vehicles and alcohol hydrogen commercial vehicles. |
Thomas pumpSuper quiet and long service life. |
Vehicle CAN communicationCan also be integrated into on-board systems via CAN interfaces. |
Applicable vehicle models ▶
|
|
|
|
|
|
|
|
|
|
Technical data ▶
| Methanol heater | PW24 Methanol Heater | PW40 Methanol Heater |
| Heating capacity（KW） | 24 | 37 |
| Outlet Temperature | 65℃ on/78 ℃ off | |
| Methanol Consumption（L/H） | 5.8 | 9.7 |
| Heating Medium | cooling liquid | |
| Fuel | M100Methanol | |
| Power consumption during operation（W） | ≤80 | ≤300 |
| rated voltage（V） | 24 | |
| Operating Voltage（V） | 18-32 | |
| Minimum throughput of heating medium（L/H） | 1200 | |
| Ambient temperature requirements（℃） | Operating environment temperature: -40 ℃ to+85 ℃ Transportation/storage: -40 ℃ to+100 ℃ Combustion air: ＜ 60 ℃ |
|
| Operating pressure of water cycle | ＜2.5bar | |
| Weight（kG） | 20 | 35.8 |
| Dimensions （MM） | 666*339*273 | 666.5*349*273 |
