Product Details
The Yusenn Magnetic Water Pump uses magnetic force to drive the impeller of the water pump, achieving hard isolation between the motor and the impeller to avoid failure caused by poor sealing. It is widely used in vehicle mounted water circulation cooling systems. The motor and impeller are driven by magnetic force, and the electrical part is completely isolated from the liquid, resulting in a long service life.
Multiple protection functionsReverse connection protection, no-load protection, locked rotor protection, overload protection, overvoltage and undervoltage protection |
Complete isolation between electrical appliances and liquidsElectrical parts are completely isolated from liquids, with an ultra long lifespan |
Applicable vehicle models ▶
Technical parameters ▶
| Magnetic Water Pump Model | 215-04000 | 141-65301 | 141-65302 |
| Voltage(V) | 24V | 24 | 24 |
| Interface diameter(MM) | 38 | 38 | 25 |
| Flow rate(L/H) | 5000 | 6000 | 1800 |
| Maximum head(M) | 8 | 8 | 8 |
| Lifespan (H) | 20000 | 20000 | 20000 |
| Noise (dBA) | ≤40(The horizontal distance of the pump body is 1 meter) | ≤60 | 45 |
| Working temperature (℃) | -40~125 | -40~85 | -40~85 |
